Powge 2GT 9mm belt – 1m
Out of stock
1.The PowerGrip GT2 system is an extension of the HTD system with greater load-carrying
capacity. HTD was developed for high torque drive applications, but is not acceptable for most precision indexing or registration applications.
2.As smaller diameter pulleys are used, the clearance required to operate properly is increased.
HTD drive clearance, using small diameter pulleys, is approximately four times greater than an equivalent GT2 timing belt drive.
3.circular arc tooth profile, tooth space is small, suitable for straight line driving.
Breaking Strength:85N Per 1mm(61 lbf per 1/8inch)Belt Width;
Working Tension:110 N for 25.4mm Belt width(24 lbf for 1inch.)
Temperature Range:-34°C to +85°C(-30°F to + 185°F)
GT2 Pitch :2mm
Material: Neoprene Rubber With Fiberglass Core
Shape:Open Timing belt
